Description
Chord’s Prima preamp forms part of the stylish and compact Choral range and has been designed to complement the Etude power amps. Despite its compact dimensions and space-saving footprint, the Prima is every bit a pedigree Chord Electronics amplifier.
Precision-machined from solid aircraft-grade aluminium billet, the Prima offers both remote control and front panel operation. Prima’s fascia offers volume and balance controls while its push-button controls atop the unit, offer input selection and tape line selection, the latter enabling its tape outputs to be selected for recording from source components. Further design features include a top panel display, offering input choice and volume information, plus a clever porthole which enables the internal circuit board to be seen.
The Prima also benefits from a custom Ultra-High-Frequency power supply, which delivers efficient and fast energy charge/discharge for delivering power to capacitors when required. Prima offers fully balanced circuitry throughout and useful flexibility with five inputs, four unbalanced RCA and one balanced XLR, plus a balanced XLR output and a tape output. For added versatility, Prima’s audio circuit offers six independent input gain adjustments for the five inputs and low impedance outputs.
Features
Inputs & Outputs:
5 Stereo Inputs and 1 Stereo Output
- 1x Stereo Balanced XLR Input – Main Line 1
- 4x Stereo Unbalanced RCA Inputs – Line In 2, Line In 3, Line In 4, and Line In
- 1x Stereo Balanced XLR Output – Output 1
- 1x Stereo Unbalanced RCA Tape Output – Tape Output
Specification
Frequency Range:
2.5Hz – 200kHz +/- 3dB
Output Impedance:
100Ω (Short Circuit Protected)
Operating Voltage:
50v – 260v AC (50Hz – 60Hz) Auto Switching
Power consumption:
30W
Dimensions:
335mm (w) x 170mm (d) x 65mm (h)
Weight:
8kG
