Description
Exposure XM3 Phono Amplifier in titanium (dark sliver) finish. Current new price is £1050
Good overall condition with only some minor scuffs on the sleeve.
Full working order, 3 month warranty. Free UK mainland shipping.
FEATURES
- Large 200VA custom made toroidal transformer for power supply
- Multiple power supply capacitors in parallel for low ESR
- All discrete transistor audio stages
- High quality resistors & capacitors used in the signal path
- Separate MM & MC inputs selectable on the back panel
- Adjustable loading & gain switches on the back panel
- High quality all aluminium case work and extruded front panel
- Three year guarantee
- Available in black or titanium
SPECIFICATIONS
Moving Magnet Input
- Sensitivity : 3.5mV input for 350mV output, 40dB gain setting
- Signal to Noise ratio, ref 1KHz & 350mV out :
- Gain Switch 4 ON : >70dB
- Gain Switch 4 OFF : >78dB
Moving Coil Input
- Sensitivity : 350uV input for 350mV output, 60dB gain setting
- Signal to Noise ratio, ref 1KHz & 350mV out : >67db A weighted. ALL gain switches (4-6)
General Specifications
- Frequency Response : 30Hz – 20Hz within +/- 0.25dB ref 1KHz with low frequency roll off below 30Hz
- Total Harmonic @ 1KHz, ref 350mV out <0.025% MC Input :
- Maximum Ouput Voltage : 7.8V RMS 1KHz
- Output Impedance : 50 ohms
- Mains Supply : 110/120V or 220/240V @ 50/60Hz (factory set)
- Power Consumption : <25W
- Dimensions (WxHxD) : 218mm x 89mm x 348mm
- Net Weight (unpacked) : 4kg
- Gross Weight (packed) : 5kg
